Extruded Silicone Tube

China extruded silicone tubes manufacturer Aobo silicone has various extruding silicone tubes include transparent silicone tubes, medical-grade silicone tubes, food-grade silicone tubes, industrial-grade silicone tubes, high-temperature resistant silicone tubes, and automotive silicone tubes, etc.

Send Inquiry

Product Description

Why are the customized extruded silicone tubes from Aobo Silicone so popular? Because we are the original extruding silicone tubes manufacturer and factory and supplier. Our extruding silicone tubes are made of high-purity silicone, which can withstand temperatures ranging from -60°C to 200°C without deformation. They boast a wide range of applications, excellent flexibility, crack resistance, safety and non-toxicity, as well as transparency for visual inspection—thus being widely favored in the medical, food and industrial sectors. With a smooth surface that resists impurity adhesion, they are ideal for conveying various liquids or gases.

Products Parameter

Tube No.	Inner Diameter		Outside Diameter		Wall Thickness
	Inch	mm	Inch	mm	Inch	mm
13	1/32	0.8	5/32	4.0	1/16	1.6
14	1/16	1.6	3/16	4.8	1/16	1.6
16	1/8	3.2	1/4	6.4	1/16	1.6
25	3/16	4.8	5/16	8.0	1/16	1.6
15	3/16	4.8	3/8	9.6	3/32	2.4
17	1/4	6.4	3/8	9.6	1/16	1.6
24	1/4	6.4	7/16	11.1	3/32	2.4
26	1/4	6.4	1/2	12.7	1/8	3.2
18	5/16	8.0	7/16	11.1	1/16	1.6
35	5/16	8.0	1/2	12.7	3/32	2.4
36	3/8	9.6	9/16	14.4	3/32	2.4
73	3/8	9.6	5/8	15.9	1/8	3.2
70	3/8	9.6	3/4	19.1	3/16	4.8
82	1/2	12.7	3/4	19.1	1/8	3.2
88	1/2	12.7	7/8	22.2	3/16	4.8
89	5/8	15.9	1	25.4	3/16	4.8
90	3/4	19.1	1 1/4	31.8	1/4	6.4
92	1	25.4	1 3/8	35	3/16	4.8

How to Select the Right Extruded Silicone Tubes?

Please choose the extruding silicone tube that suits you based on the details below.

Confirm Specifications: The tolerance of inner/outer diameter shall not exceed ±0.5mm.

Check Appearance: High-quality extruded silicone tubes feature a smooth surface without impurities.

Test Rebound Performance: The tube shall bounce back quickly after being pinched and pressed.

Check Odor: Qualified products only have a slight silicone smell.

Special Requirements: Choose additive-modified products when electrical conductivity or antistatic properties are needed.

What Are the Properties of Extruded Silicone Tubes?

The extruded silicone tubes manufactured by Aobo silicone have the following properties:

1.Non-toxic, odorless and highly transparent;

2.Soft with excellent elasticity, resistant to kinking and deformation;

3.Crack-resistant, long service life, resistant to low and high temperatures;

4.Higher tear strength and superior electrical properties.

What Is the Function of Extruded Silicone Tubes?

Extruded silicone tubes are used for sealing equipment in automotive, chemical, instrumentation, machinery, daily necessities, furniture, electronics and electrical appliances industries, such as sealing household appliances including electric steamers, refrigerators, freezers, disinfection cabinets, electric ovens, pressure cookers, rice cookers, soybean milk makers, electric kettles, solar water heaters, and sealing machines.
